Polyester Eye And Eye Sling , Webbing Lifting Slings For Lifting Equipment

Polyester Eye And Eye Sling , Webbing Lifting Slings For Lifting Equipment

    • Polyester Eye And Eye Sling , Webbing Lifting Slings For Lifting Equipment
    • Polyester Eye And Eye Sling , Webbing Lifting Slings For Lifting Equipment
    • Polyester Eye And Eye Sling , Webbing Lifting Slings For Lifting Equipment
  • Polyester Eye And Eye Sling , Webbing Lifting Slings For Lifting Equipment

    Product Details:

    Place of Origin: JiangSu China
    Brand Name: Slingman
    Certification: CE GS TUV ISO
    Model Number: TSUWB04-5

    Payment & Shipping Terms:

    Minimum Order Quantity: 100
    Price: Negotiate
    Packaging Details: Film shrinked with outer carton
    Delivery Time: 35 days since order confirmed
    Payment Terms: TT DP
    Supply Ability: 20000 Per month
    Contact Now
    Detailed Product Description
    Color: Yellow Material: Polyester
    Standard:: ASMEB30.9 Brand: Slingman
    Type: Web Sling Certification: CE GS TUV ISO
    Label: Orange Place Of Origin: JiangSu China
    Shape: Flat Pattern: Flat Woven Pattern Webbing
    Lifting Eye Type: Flat Eyes Safety Factor: 5 To 1

    Polyester Eye And Eye Sling , Webbing Lifting Slings For Lifting Equipment







    WLL      11500 LBS

    Width    4 Inch

    Length   As client request

    Colour   Yellow

    Standard   ASMEB30.9

    Certification    CE GS TUV ISO
    Safety Factor  5 to 1   Class 7, we can produce class 5 as well.

    Package    Film shrinked with outer carton and Pallet      20 Pallets per 20 feet container



    1  100% high tenacity polyester fiber.  Double A Class raw material fiber

    2  Double Plies slings. Of course , we can make one ply, three plies and four plies as well.

    3  With reinforcement on lifting eyes.

    4  100% polyester sewing thread



    Flat Eye & Eye Lifting Slings

    Flat Eye & Eye (EE) lifting slings are made with a flat loop eye on each end. The slings have a loop eye opening on the same plane as the sling body.

    This type of sling goes by a variety of names including flat eye and eye, eye and eye and double eye sling.

    The flat eye and eye slings are versatile and flexible. They can be used with all three hitches: vertical, basket and choker.











    Features

    Single Use - One Way

    Low cost, simple design

    Easy to use

    Stronger and more compact than rope or wire rope alternative solutions.

    Can be attached or built in to a structure or load, but must only be used to perform a single complete lift.

    Saves time and cost on-site slinging and reslinging loads.

    Fully manufactured, labelled and tested in accordance with BS EN 1492-1:2000 or upon request, manufactured to your commercial specifications with supporting technical file.

    Available as standard in 25mm, 35mm and 50mm widths in endless format or as bespoke units with loops each end.









    WARNING



    Inspect slings each day before use, looking for:

    Missing or unreadable ID tag
    Melted, charred or weld-splattered areas
    Acid or alkali burns
    Holes, tears, cuts, snags or embedded particles
    Broken or worn stitching
    Excessive abrasive wear or elongation
    Knots or brittle areas
    Broken, corroded, pitted distorted fittings

    Do not use worn or damaged slings or attachments. Discard or repair them. Use damaged slings only after they are repaired, reconditioned, and proof tested by the sling manufacturer or a qualified person. Keep certificates of proof test.



    Maintenance requirements are minimal. Belt slings may be cleaned with clear water. Remember weak chemical

    solutions will become increasingly stronger by evaporation. Regularly inspect belt slings and, in the event of the

    following defects, refer the sling to a Competent Person for thorough examination: illegible markings; damaged,

    chaffed or cut webbing; damaged or loose stitching; heat damage; burns; chemical damage; solar degradation;

    damaged or deformed end fittings.



    Inspect slings each day before use, looking for:



    Missing or unreadable ID tag
    Melted, charred or weld-splattered areas
    Acid or alkali burns
    Holes, tears, cuts, snags or embedded particles
    Broken or worn stitching
    Excessive abrasive wear or elongation
    Knots or brittle areas
    Broken, corroded, pitted distorted fittings

    Do not use worn or damaged slings or attachments. Discard or repair them. Use damaged slings only after they are repaired, reconditioned, and proof tested by the sling manufacturer or a qualified person. Keep certificates of proof test.

    Maintenance requirements are minimal. Belt slings may be cleaned with clear water. Remember weak chemical
    solutions will become increasingly stronger by evaporation. Regularly inspect belt slings and, in the event of the
    following defects, refer the sling to a Competent Person for thorough examination: illegible markings; damaged,
    chaffed or cut webbing; damaged or loose stitching; heat damage; burns; chemical damage; solar degradation;
    damaged or deformed end fittings.
