Home ProductsEye And Eye Sling

High Performance Endless Flat Lifting Slings With Reverse Eye Environment Friendly

High Performance Endless Flat Lifting Slings With Reverse Eye Environment Friendly

High Performance Endless Flat Lifting Slings With Reverse Eye Environment Friendly

Product Details:

Place of Origin: JiangSu China
Brand Name: Slingman
Certification: CE GS TUV ISO
Model Number: TSUWB04-5

Payment & Shipping Terms:

Minimum Order Quantity: 100
Price: Negotiate
Packaging Details: Film shrinked with outer carton
Delivery Time: 35 days since order confirmed
Payment Terms: TT DP
Supply Ability: 20000 Per month
Contact Now
Detailed Product Description
Color: Yellow Material: Polyester
Standard:: ASMEB30.9 Brand: Slingman
Type: Web Sling Certification: CE GS TUV ISO
Label: Orange Place Of Origin: JiangSu China
Shape: Flat Pattern: Flat Woven Pattern Webbing
Lifting Eye Type: Flat Eyes Safety Factor: 5 To 1

High Performance Endless Flat Lifting Slings With Reverse Eye Environment Friendly



WLL      11500 LBS

Width    4 Inch

Length   As client request

Colour   Yellow

Standard   ASMEB30.9

Certification    CE GS TUV ISO
Safety Factor  5 to 1   Class 7, we can produce class 5 as well.

Package    Film shrinked with outer carton and Pallet      20 Pallets per 20 feet container



1  100% high tenacity polyester fiber.  Double A Class raw material fiber

2  Double Plies slings. Of course , we can make one ply, three plies and four plies as well.

3  With reinforcement on lifting eyes.

4  100% polyester sewing thread







Product Detail



1. Sling can be fabricated from single or multiple plies, may include accessories such as edge guard,wear pads or sleeves, and are available in several configurations.
2. Loading surface is wide to reduce the weight at each loading point, no damage to tender objects.
3. Anti-abrasion and anti-incision protection sleeve can be attached.
4. Has special label working loads is differentiated by colors according to international standard easy to identify even if the sling has abased.
5. Light and soft, can bu used in small narrow space.
6. In PU processing anti-danger of electric stroke.
7. The working temperature range-40℃-100℃.





Features

Single Use - One Way

Low cost, simple design

Easy to use

Stronger and more compact than rope or wire rope alternative solutions.

Can be attached or built in to a structure or load, but must only be used to perform a single complete lift.

Saves time and cost on-site slinging and reslinging loads.

Fully manufactured, labelled and tested in accordance with BS EN 1492-1:2000 or upon request, manufactured to your commercial specifications with supporting technical file.

Available as standard in 25mm, 35mm and 50mm widths in endless format or as bespoke units with loops each end.









WARNING

Do not use strap if there are any signs of cut webbing, heat or chemical damage.
Do not attempt to use strap above rated capacity.
Alternate hardware available
Webbing straps must be protected when used on rough or sharp objects. Straps that are cut, worn or otherwise damaged should not be used.
A strap is only as strong as its weakest component.



Our Services



1. Client

We treasure and try to understand all the different needs of our clients and seek to forge a long term professional relationship with them. The satisfaction of each and every customer is our main goal and motivation in conducting our business.

2. People

We work as a team and treat each other with respect. Our solid, capable and knowledgeable team is valued as the greatest asset and an integral part of the business.

3. Product

Our products are of HIGH quality standards and always come with certificate of compliance by the manufacturers.

4. Free sample and OEM service

We can provide free samples to you and we also have OEM service, we can put your logo on the label and the information you need on the webbing too.
